| Case Size | 72 x 72 x 65 |
|---|---|
| Panel Hole Size | 67 x 67 |
| Range Limit | 4-5000 RPM |
| Input | NPN, PNP proxy |
| Function | Scale Factor / High & Low Set Point |
| Sensor Supply | 12 VDC / 30 mA |
| Input Speed | 0 - 10 KHz |
| Accuracy | +/- 1 Count |
| Control Action | ON-OFF |
| Output | 2 Relay (220VAC / 5Amp) |
| Display | 4digit Dual Display, Bright Red Seven Segment |
| Keyboard | 4 Keys |
| Indication | Indication For Relay Status |
| Front Protection | ABS Plastic Body |
| Power Supply | 85 to 270 VAC smps supply |
| Enviornment | Temp : 0 - 50°C / Rh : 35 - 85 % ( Non - Condensation ) |
