| Case Size | 96 x 96 x 90 |
|---|---|
| Panel Hole Size | 92 x 92 |
| Range Limit | 0-9999 Amp |
| Input | 5 Amp, Ct Ration Selectable |
| Accuracy | +/- 0.5% of FS |
| Resolution | Selectable Resolution |
| Function | High / Low alarm, Power on Delay time |
| Output | 1 Relay output |
| Control Action | On-Off with hysteresis band |
| Display | 4 Digit Dual Display |
| Indication | Indication For Relay Status |
| Keyboard | 4 Keys |
| Front Protection | ABS Plastic Body |
| Mounting | Flush Panel Mounting With Side Clamp |
| Power Supply | 230 VAC+/- 10%, 50 HZ |
| Enviornment | Temp : 0 - 50°C / Rh : 35 - 85 % ( Non - Condensation ) |
