| Case Size | 96 x 96 x 45, 92 x 92 |
|---|---|
| Range Limit | 0-99999.9 KWH / 0-999.9 KW |
| Input | 5 Amp CT Selectable / Volt: 0-500 VAC |
| Function | Single Phase : KWH, KW |
| Accuracy | +/- 0.5% of FS |
| Display | 6 Digit KWH, 4 Digit KW |
| Keyboard | 4 Keys |
| Front Protection | ABS Plastic Body |
| Mounting | Flush Panel Mounting With side clamp |
| Power Supply | 230 VAC +/- 10%, 50 HZ |
| Enviornment | Temp : 0 - 50°C / Rh : 35 - 85 % ( Non - Condensation ) |
