| Case Size | 96 x 96 x 90 |
|---|---|
| Panel Hole Size | 92 x 92 |
| Range Limit | 0-9999 Flow rate, 0-99999999 Total Flow |
| Input | 4-20 mA / Pulse |
| Accuracy | +/- 0.5% of FS |
| Resolution | 0.1 For Flow Rate |
| Function | LPM / LPH / M3-HR Unit Selectable, Square root function for flow |
| Output | 1 Relay / 4-20 mA / RS-485 (Factory set) |
| Control Action | On-Off with hysteresis band |
| Display | 8 Digit for total flow, 4 Digit Flow rate |
| Indication | Indication For Relay Status |
| Keyboard | 4 Keys |
| Front Protection | ABS Plastic Body |
| Mounting | Flush Panel Mounting With Side Clamp |
| Power Supply | 230 VAC+ 10%, 50 HZ |
| Enviornment | Temp : 0 - 50°C / Rh : 35 - 85 % ( Non - Condensation ) |
