| Case Size | 96 x 96 x 90 |
|---|---|
| 70 x 45 | |
| Panel Hole Size | 92 x 92 |
| Range Limit | 0-50000 |
| Input | Load cell sensor |
| Resolution | Selectable |
| Calibration | Software calibration of load |
| Output | 1 / 2 / 3 Relay, 4-20mA, 0-10 VDC, RS 485 Modbus (Factory Set) |
| RS - 485 modbus, communication | |
| Control Action | On-Off with hysteresis band |
| Display | 5 Digit Dual Display |
| Indication | Indication For Relay Status |
| Keyboard | 6 Keys |
| Front Protection | ABS Plastic Body |
| Mounting | Flush Panel Mounting With Side Clamp |
| Din Rail / Channel mount | |
| Power Supply | 230 VAC +/- 10%, 50 HZ |
| Enviornment | Temp : 0 - 50°C / Rh : 35 - 85 % ( Non - Condensation ) |
