| Case Size | 72 x 72 x 75 |
|---|---|
| Panel Hole Size | 67 x 67 |
| Sensor | T/C : K, J |
| Range Limit | J (0-400 °C), K (0-1200°C) |
| Accuracy | +/- 0. 5 % OF FS |
| Resolution | 1 °C for J/K type TC, 0.1 °C for RTD |
| Current | 0-99.9 Amp |
| Control Action | PID / ON-OFF |
| Output Type | 2 Relay |
| Output | Relay 220 VAC / 3 A, 12 VDC for SSR |
| Display / color | 4 Digit / 3 Row Display |
| Keyboard | 4 keys |
| Indication | Indication for Relay / Current Indication |
| Mounting | Flush Panel Mounting With Side Clamp |
| Power Supply | 230 VAC, 50- 60 Hz, + 10 %, > 5 VA |
| Enviornment | Temp : 0 - 50°C / Rh : 35 - 85 % ( Non - Condensation ) |
