| Processor | 32 Bit Multitasking Processor |
|---|---|
| Memory | 128 MB Flash Memory |
| Program Capacity | 16 KB |
| Execution Speed | < 0.2 MicroSec |
| Data Register | 8 K Words |
| Display | 4.3" TFT |
| Resolution | 480 x 272 Pixels |
| Color | 65535 Colors |
| Backlight | Led |
| Touchpanel | Resistive Touch panel |
| RTC | Inbuilt RTC & Buzzer |
| PLC | USB / COM PORT |
| HMI | SD CARD |
| Supported File | Video / Audio / GIF's / QR code |
| Serial Port | Serial Port Modbus RTU (Master / Slave congurable Mode) baud rate up to 115.2 Kbps |
| Inbuilt I/O's | 8*DI / 8*DO ( Max 32 Point ) |
| DI | Upto Max -12 DI ( NPN Type ) |
| DO | Upto Max -16 DO ( Relay or Transistor ) Relay : 3 Amp / 230 VAC |
| Temp | Upto Max -4 Ch T/C or RTD Predened |
| Analog Input | Upto Max -4 CH Analog Input ( 0 - 10 VDC / 4 -20 mA Predened) |
| Analog Output | Upto Max -8 CH Analog Output ( 0 - 10 VDC / 4 -20 mA Predened) |
| Highspeed | Upto Max -4 CH HighSpeed Pulse Output ( 64 KHz ) |
| Shell Color | Grey |
| Shell Material | ABS |
| Mounting | Panel Mounting with Side Bracket |
| Dimension | 164 x 129 x 43 MM ( W x H x D ) |
| Panel Cutout | 157 x 122 MM ( W x H ) |
| Power Supply / Consumption | 24 VDC, > 5 W |
| Working Environment | Temp : 0 -50*C / RH : 35 - 85 % ( Non- Condensation ) |
| Protection | IP-65 ( Front Panel ) |
