| Case Size | 96 x 96 x 45, 72 x 72 x 65, 48 x 48 x 75 |
|---|---|
| Panel Hole Size | 92 x 92, 67 x 67, 46 x 46 |
| Range Limit | 0-99999.9 Meter |
| Input | NPN/ PNP Proximity, Potential Free Contact, Photosell |
| Sensor Supply | 12 VDC / 30 mA |
| Input Speed | 10 KHz |
| Accuracy | +/- 1 Count |
| Function | Diameter / PPR Setting |
| Output | 1 Relay |
| Relay | 230 VAC / 5 AMP |
| Counting | Up |
| Display | 6 Digit Upper / 4 Digit Lower Display , 6 Digit Total Length / 4 Digit MPM |
| Keyboard | 4 Keys |
| Reset | Auto / Manual - Front / Back Reset |
| Memory | Yes (Non-Volatile Memory |
| Front Protection | ABS Plastic Body |
| Mounting | Flush Panel Mounting With Side Clamp |
| Power Supply | 230 VAC +/- 10%, 50 HZ |
| Enviornment | Temp : 0 - 50°C / Rh : 35 - 85 % ( Non - Condensation ) |
