| Case Size | 96 x 96 x 45, 72 x 72 x 65, 48 x 48 x 75 |
|---|---|
| Panel Hole Size | 92 x 92, 67 x 67, 46 x 46 |
| Range Limit | 0-9999 Count |
| Input | NPN/ PNP Proximity, Potential Free Contact, Photocell |
| Sensor Supply | 12 VDC / 30 mA |
| Accuracy | +/- 1 Count |
| Function | 4 Digit Counter |
| Output | 1 Relay / Buzzer - NO/ NC (230 VAC / 5 AMP), Buzzer - 12 VDC, 10 mA |
| Counting | Up / Down |
| Display | 4 Digit Dual Display |
| Keyboard | 4 Keys |
| Reset | Auto / Manual - Front / Back Reset |
| Memory | Yes (Non-Volatile Memory) |
| Front Protection | ABS Plastic Body |
| Mounting | Flush Panel Mounting With Side Clamp |
| Power Supply | 90-270 VAC, 50 HZ |
| Enviornment | Temp : 0 - 50°C / Rh : 35 - 85 % ( Non - Condensation ) |
