| Case Size | 96 x 96 x 45 |
|---|---|
| Panel Hole Size | 92 x 92 |
| Range Limit | Temp.: 0-150°C / RH: 0-100% |
| Input | Temp.: PT-100 / Capacitive RH Sensor (3.3VDC / 4-20mA) |
| Accuracy | + 1°C for Temperature, + 2% for RH |
| Resolution | 0.1°C for Temperature, 1% for RH |
| Function | PID / On- Off action Selectable |
| Output | 2/3 Relay output |
| Display | 4 Digit Dual Display |
| Keyboard | 4 Keys |
| Front Protection | ABS Plastic Body |
| Mounting | Flush Panel Mounting With Side Clamp |
| Power Supply | 230 VAC +/- 10%, 50 HZ |
| Enviornment | Temp : 0 - 50°C / Rh : 35 - 85 % ( Non - Condensation ) |
