| Case Size | 48 x 48 x 75 |
|---|---|
| Panel Hole Size | 46 x 46 |
| Range Limit | 9.99 / 99.9 / 999 |
| Unit | Sec./ Min./ Hr. |
| Mode | On Delay / Preset / Cyclic |
| Set Poin | 2 Set Point |
| Output | 1 Relay (1 C/O) |
| Description | Relay (5 Amp / 230 VAC) |
| Display | 3 Digit Single Display |
| Color | Red |
| Keyboard | Feather Touch Key Board |
| Start Input | Proximity / Potential Free Contact / Power On Start |
| Indication | Indication For Relay Status |
| Function | Front / Back Reset / Up - Down Count / Memory Selection ( Yes/No) |
| Front Protection | ABS Plastic Body |
| Mounting | Panel Mounting with side Clamp |
| Power Supply | 90 - 270 VAC, 50 Hz |
| Enviornment | Temp : 0 - 50°C / Rh : 35 - 85 % ( Non - Condensation ) |
